Machinery manufacturing

Development of Machinery manufacturing directly reflects a country's degree of industrialization; it is an important symbol of national industrial strength. China has gradually become the world's leading industrial powers. 3 d measurement technology has a broad application prospect in the field of machinery manufacture, can provide variety of solutions for industry development.


1.Detection

Most tradition way of detecting adopts contact way to do the detect, such as use the clamp fixture, which has high accuracy but low efficiency. What’s more, it may damage the objects.

The HSCAN and ZSCAN optical measurement equipment, Using optical principle for surveying and mapping. Provide reliable 3d data on the premise of no damage of scanned object. And the scanning is not restricted by the size of the object. Corporate with the MSCAN can sharply reduce the cumulative error of large objects. Comparing the 3d data to 3d drawings, can obtain the deviation of the objects, which provide basis of the later develop. The convenient scan also greatly improves the efficiency of detection, reducing time and manpower cost.


2.Modeling design

3d scan can also be used in the mechanical reversal design. Obtain the contour data and do the analyze, reverse design the product drawings for processing. Structure compound can be achieved through the reverse modeling, which have important implications in data save and technology innovations.


3.Maintain

The HSCAN hand held 3d scanner can obtain the 3d data of those key component. Get the dimension through the professional digital analyze, provide the technical support for the maintain.


4.Detection

Those key parts would have wear during use procedure, and it should be repair. The HSCAN 3d scanner can obtain the 3d data and do the compare to the original drawings. The deviation could be seen clearly. Precise measurement also provides a basis for the model repair.
